DGS Multipair, single shielded snakes, compact and high flex!

Each pair of conductors is protected by our exclusive "single Reussen shield". DGS multipair cables come in various combinations from 4pair up to 48pair, per meter, in cut length or standard spools. All multipair cables are numbered each meter for easy length termination. Most flexible multipair cable in the industry.  Each line is similar to our 40301 single shielded signal line
LFOC higher grade copper at best standards for best performance.



Construction of Multipair:

1 = Jacket: PVC
2 = Viscose fiber coat: Counter wrapped
3 = Jacket: PVC, 3.30 mm max. Ø
4 = Shield: 64 bare copper wires, (0.10 mm) 100% coverage
5 = Insulation: PE, Ø 1.15 mm, conductors, red and white wrapped
6 = Conductor: Stranded bare copper wires 25 x 0.10 mm (0.19mm²)25x38AWG =  24AWG

Technical Datas:

Conductor resistance:    < 90 ohm/km
Shielding resistance:    < 40 Ohm/km
Capacitance: cond/cond:  < 80 nF/km
  cond/shield:  < 121 nF/km
Characteristic impedance: at 20 kHz 145 Ohm
Test voltage: cond/cond:  500 veff
  cond/shield:  2000 veff
Operating voltage:   low voltage
Temperature range: flexi-installed: -5° to +50° C
  fix-installed: -30° to +70° C

Construction of the multipair cable 34004 (4 pair)

Jacket: PVC, maximaler Ø 8.50 mm schwarz
Spool size: 300m
Weight/m: 0.10 kg
Weight/spool: 30.00 kg

Construction of the multipair cable 34006  (6 pair)     Speziell auch für DPA 5100 Surround Mikrofon

Jacket: PVC, maximaler Ø 9.00 mm schwarz
Spool size: 100m  (ab Deutschland nur  in Karton 2x100m)
Weight/m: 0.12 kg
Weight/spool: 12.00 kg

Construction of the multipair cable 34008  (8 Pair)

Jacket: PVC, maximaler Ø 13.0 mm schwarz
Spool size: 200m
Weight/m: 0.20 kg
Weight/spool: 40.00 kg

Construction of the multipair cable 34048  (48 Pair)

Jacket: PVC, maximaler Ø 30.00 mm schwarz
Spool size: 100m
Weight/m: 0.50 kg
Weight/spool: 52.00 kg

Ordering Information:

Order No. Type Type Colour Spool Size Weight/
 Shipping Unit
34004 DGS-4paar 8.50 mm black 300m 30.00 kg 1x300m HS400
34006 DGS-6paar 9.0 mm black 100m (Carton 2x100m) 12.00kg (24kg Carton) 1xCarton mit 2x100m H300
34008 DGS-8paar 13.0 mm black 200m 40.00kg 1x200m HS400
34048 DGS-48paar 30.00 mm black 100m 52.00kg 1x100m HS400

Retail Prices July 2022:

Order Nr. Analog Multipaar Cables Length/
Color Standard Spool CHF (Swiss Francs) Export EUR
per spool * per meter per spool * per meter
34004 DGS-4pair max. 300 m black  1x300m 1'350.90  4.45 1'194.55 3.95
34006 DGS-6pair mini zu DPA 5100 max. 100 m black  Box 2x100m  547.70  5.50 484.35 4.85
34008 DGS-8pair max. 200 m black  1x200m 1'630.80 8.20 1'442.10 7.25
34048 DGS-48pair max. 100 m black 1x100m 4'077.00 40.75 3'605.25 36.05
Please see ordering Information link:   (No minimum Order!)
Terms: CHF (Swiss Francs) Price is including Swiss Domestic 7.70%  VAT.
Ex works Dietikon Switzerland. Packing and crate included. You can collect your order in Dietikon w/o any shipping fees.

Sold per meter as per your order. We cut every cable to your order. Maximum continues length is a standard spool.
*Price per meter charged per actual measurement. We can only sell / invoice full meters.

Shipment from stock in Switzerland:  we can ship from Swiss sales office in Dietikon Switzerland. No minimum Order
Orders from Swiss warehouse can consolidate other products from our domestic range (such as connectors) and cables could be cut to order and/or even terminated with connectors.
Example of a cable spool as stored in Germany and Switzerland
Check possible remant spools/leftover pieces at special prices from Swiss warehouse!  Link to Sales items
shipment from warehouse in Germany:  c/o bonded warehouse c/o Streck Transport GmbH in Freiburg (Germany) for shipments.
Multipair cannot be cut in Germany warehouse. You need to order/take spools actually available.
Check with us individual spool sizes possibly available. Standard spool are available.
Attention: German clients and EC clients w/o UID (Vat identification) number will be charged with 19% German VAT in addition!
Minimum order for shipments from Germany warehouse is for each line item 1pc standard shipping unit or multibles thereof.

**shipping unit/standardspool: The shipping units rules do only apply for orders being shipped from bonded warehouse in Germany. From our Swiss headquarters we can ship any quantify, per cut meter, full spool or shipping unit!

Full Pricelists download to be found here:  Link

Please inquire via contact and avoid entering all datas. You can also simply send us an email to info@gotham.ch
